Straight pipe jacking guidance system
Product Offering
Straight Pipe Jacking Automatic Guidance System
直线顶管自动导向系统
Automatic guidance system for straight pipe jacking, using customized laser theodolites and dual-screen laser targets for real-time position and attitude guidance
面向直线顶管施工的自动导向系统，采用定制激光经纬仪和双屏激光靶实现实时位姿导向
Supplied by Raising Measurement (Shanghai) Co., Ltd.
Overview
Product overview
The Straight Pipe Jacking Automatic Guidance System is designed for pipe jacking construction processes. It uses customized laser theodolites and a dual-screen laser target solution to measure pipe jacking machine position and orientation. The system calculates horizontal and vertical deviations, advancement mileage, and horizontal and vertical trends in real time, and displays guidance information through integrated graphical and numerical interfaces. Wireless communication for the dual-screen targets reduces routine maintenance work for survey personnel.
直线顶管自动导向系统面向顶管施工工艺设计，采用定制激光经纬仪和自主研发的双屏激光靶方案，实现顶管机位姿测量。系统实时计算顶管机水平偏差、垂直偏差、掘进里程、水平趋向和垂直趋向，并以图形和数字结合的方式显示导航信息，辅助司机控制顶管机沿设计轴线推进。双屏标靶采用无线通讯方式，可减少测量人员维护工作。
Applications
Typical applications
- Straight pipe jacking
- Municipal pipeline construction
- Natural gas pipeline crossing
- Trenchless pipeline construction
- Pipe jacking and shield combined construction
- Underground pipeline alignment control
- 直线顶管施工
- 市政管线施工
- 天然气管线穿越
- 非开挖管线施工
- 顶管与盾构组合施工
- 地下管线轴线控制
Features
Key product features
- Customized laser theodolite measurement
- Dual-screen laser target solution
- Real-time position and orientation measurement
- Horizontal and vertical deviation calculation
- Advancement mileage calculation
- Graphical and numerical guidance display
- Wireless communication for dual-screen targets
- Reduced survey maintenance workload
- 定制激光经纬仪测量
- 双屏激光靶方案
- 实时位姿测量
- 水平和垂直偏差计算
- 掘进里程计算
- 图形与数字导向显示
- 双屏标靶无线通讯
- 减少测量维护工作量
Technical Information
Technical parameters
Technical approach
- Measurement components: Customized laser theodolites and dual-screen laser targets.
- Communication mode: Wireless communication for dual-screen targets.
- Calculated values: Horizontal deviation, vertical deviation, advancement mileage, horizontal trend, vertical trend.
技术参数
技术实施要点
- 测量组件：定制激光经纬仪和双屏激光靶。
- 通讯方式：双屏标靶无线通讯。
- 计算内容：水平偏差、垂直偏差、掘进里程、水平趋向、垂直趋向。
