T-600 Shield Tail Sealant Grease (Pumpable Type)

T-600盾尾密封油脂（泵送型）

T-600 Shield Tail Sealant Grease is a pumpable sealant grease for shield tunneling, providing sealing, waterproofing and lubrication between the shield tail, tail brush and segments.

T-600盾尾密封油脂是面向盾构施工的泵送型密封油脂，用于盾尾、盾尾刷及管片之间的密封、防水和润滑。

Supplied by Baolifu New Materials (Guangzhou) Co., Ltd.

View Supplier Profile

Overview

Product overview

T-600 Shield Tail Sealant Grease is a uniform paste produced from fibers, thickeners, fillers, sealants and other materials through a specialized process. It is designed for shield tunneling applications where sealing, waterproofing and lubrication are required.

The product helps prevent mortar and groundwater outside the shield machine from seeping into the machine. When segments exit the shield tail, a layer of grease is applied on the outer side of the segment to reduce friction between the segment and the shield tail. The product is suitable for pump-fed shield tail sealing operations requiring stable pumpability and water impact resistance.

T-600盾尾密封油脂是由纤维、增稠剂、填料、密封剂等材料经特殊工艺制成的均匀膏状材料，适用于需要密封、防水和润滑的盾构施工场景。

该产品可防止盾构机外部砂浆和地下水渗入机内；当管片推出盾尾时，可在管片外侧形成油脂层，减少管片与盾尾之间的摩擦。该产品适用于需要稳定泵送性能和抗水冲击性能的盾尾密封作业。

Applications

Typical applications

Shield tail sealing
Shield tunneling waterproofing
Tail brush protection
Segment exit lubrication
Groundwater and mortar ingress prevention
Pump-fed sealing grease systems

盾尾密封
盾构施工防水
盾尾刷保护
管片出盾尾润滑
防止地下水和砂浆侵入
泵送型密封油脂系统

Features

Key product features

Pumpable shield tail sealant grease
Water-resistant sealing performance
Good lubricity
Excellent pumpability over a wide temperature range
Strong water impact resistance
Suitable for shield tunneling sealing and lubrication

泵送型盾尾密封油脂
具备耐水密封性能
润滑性能良好
宽温度范围内具有较好泵送性
抗水冲击能力强
适用于盾构施工密封和润滑

Technical Information

Technical parameters

Product standard

Complies with Q/KST700-2005 test standard.

Typical data

Appearance: yellow fibrous uniform grease.
Metal corrosion: no corrosion after 30 days on iron plate at room temperature.
Penetration: 220-270, 0.1 mm.
Evaporation loss at 80°C for 5 h: ≤2.5%.
Density at 25°C: 1.3 g/cm³.
Pumpability at 25°C and 8 bar: ≥20 g/min.
Water-resistant sealing at 25°C, 20-mesh screen, 3.5 MPa for 1 h: no water leakage.
Adhesion at 25°C: sliding displacement ≤10 mm in 10 min.

Packaging and storage

250 kg/barrel; customized packaging available.
Shelf life: 12 months unopened.
Store in a clean, dry and dark place.
Avoid mixing with other greases.

技术参数

产品标准

符合 Q/KST700-2005 检测标准。

典型参数

外观：黄色纤维状均匀油脂。
金属腐蚀：室温下铁片 30 天无腐蚀。
针入度：220-270，0.1 mm。
80°C、5 h 蒸发损失：≤2.5%。
25°C 密度：1.3 g/cm³。
25°C、8 bar 泵送性：≥20 g/min。
25°C、20 目筛、3.5 MPa、1 h 耐水密封：无漏水。
25°C 粘附性：10 min 滑动位移 ≤10 mm。

包装与储存

250 kg/桶，可按需求定制包装。
未开封保质期 12 个月。
储存于清洁、干燥、避光处。
避免与其他油脂混用。
