Product Offering
P-700 Shield Tunneling Foaming Agent
P-700盾构泡沫剂
P-700 Shield Tunneling Foaming Agent is a soil conditioning additive for shield tunneling, improving muck plasticity and fluidity while supporting excavation face stability and smoother muck discharge.
P-700盾构泡沫剂是用于盾构施工渣土改良的添加剂，可改善渣土塑性和流动性，支持开挖面稳定和顺畅排渣。
Supplied by Baolifu New Materials (Guangzhou) Co., Ltd.
Overview
Product overview
P-700 Shield Tunneling Foaming Agent is compounded with surfactants, stabilizers, penetrants and other ingredients. During shield tunneling, it is mixed with water and compressed air to generate micro-bubbles through the foaming devices of the cutterhead, pressure chamber and soil discharger.
The bubbles mix with excavated soil to improve muck plasticity and fluidity, maintain excavation face stability, protect cutting tools, reduce wear on the soil discharge system and support smooth shield tunneling. The product is non-toxic and non-corrosive, and the foam can disappear automatically after reaching the ground due to pressure changes.
P-700盾构泡沫剂由表面活性剂、稳定剂、渗透剂等组分复配而成。盾构施工过程中，产品与水和压缩空气混合，通过刀盘、土仓和螺旋输送机等部位的泡沫装置产生微细气泡。
泡沫与开挖土体混合后，可改善渣土塑性和流动性，维持开挖面稳定，保护刀具，降低排土系统磨损，并保障盾构施工顺利推进。该产品无毒、无腐蚀性，泡沫到达地面后可随压力变化自动消散。
Applications
Typical applications
- EPB shield soil conditioning
- Muck plasticity and fluidity improvement
- Excavation face stability control
- Screw conveyor plug formation
- Muck discharge improvement
- Wear reduction for soil discharge systems
- 土压平衡盾构渣土改良
- 渣土塑性和流动性改善
- 开挖面稳定控制
- 螺旋输送机土塞形成
- 排渣性能改善
- 排土系统磨损降低
Features
Key product features
- Improves soil plasticity and fluidity
- Maintains excavation face stability
- Enhances muck workability in sealed chambers
- Supports easier muck discharge
- Helps reduce wear of soil discharge systems
- Non-toxic, non-corrosive and biodegradable
- 改善土体塑性和流动性
- 维持开挖面稳定
- 提升密封土仓内渣土和易性
- 便于渣土排出
- 有助于降低排土系统磨损
- 无毒、无腐蚀性并可生物降解
Technical Information
Technical parameters
Recommended dilution:
- Dilute with water by 20-30 times; adjust according to site conditions.
Bubble and foam performance:
- Bubble diameter: 30-400 μm.
- Appearance: colorless and transparent.
- Density at 25°C: 1.03±0.03 g/cm³.
- pH value: 6.0-9.0.
- Foaming ratio at 0.3 MPa air pressure, 25°C water temperature, 3% concentration and 1200 rpm: ≥20.
- Water solubility: fully soluble.
- Foam support force after 15 min: ≥30 mN/m.
- Half-life at 0.3 MPa air pressure, 20°C water temperature and 3% concentration: ≥20 min.
Packaging and storage:
- 1200 kg or 1000 kg environmental protection barrel.
- Shelf life: 12 months unopened.
- Store in a cool and ventilated place and avoid freeze-thaw cycles.
技术参数
推荐稀释：
- 与水稀释20-30倍，具体比例可按现场条件调整。
泡沫及性能参数：
- 气泡直径：30-400 μm。
- 外观：无色透明。
- 25°C 密度：1.03±0.03 g/cm³。
- pH值：6.0-9.0。
- 0.3 MPa气压、25°C水温、3%浓度、1200 rpm条件下发泡倍率：≥20。
- 水溶性：完全溶解。
- 发泡15 min后泡沫支撑力：≥30 mN/m。
- 0.3 MPa气压、20°C水温、3%浓度条件下半衰期：≥20 min。
包装与储存：
1200 kg或1000 kg环保桶。 未开封保质期12个月。 储存于阴凉通风处，避免冻融循环。
