Tunnel cross-section inspection image
Engineering Service
Clearance Gauge Measurement
限界测量
Clearance gauge measurement solution for railway and metro tunnels, supporting cross-section CAD drawings, Excel reports, user-defined vehicle profiles, gauge templates, and clearance evaluation
面向铁路和地铁隧道的限界测量方案，可支持断面CAD图、Excel报告、自定义车辆轮廓、限界模板和限界评估
Supplied by Shanghai Bofa Spatial Information Technology Co., Ltd.
Overview
Service overview
The clearance gauge measurement solution uses tunnel cross-section data and spatial measurement results to evaluate tunnel clearance conditions. It supports user-defined vehicle, profile, gauge, and DXF templates, and generates clearance gauge reports for rail transit and tunnel infrastructure inspection.
限界测量方案基于隧道断面数据和空间测量成果，对隧道限界状态进行评估。系统支持自定义车辆、轮廓、限界和DXF模板，并可生成限界测量报告，适用于轨道交通及隧道基础设施检测。
Scope
Service scope
Key components that may be provided for relevant engineering scenarios.
- Cross-section CAD drawing output
- Excel report output
- User-defined vehicle profiles
- User-defined gauge templates
- DXF template support
- Clearance gauge report generation
- 断面CAD图输出
- Excel报告输出
- 自定义车辆轮廓
- 自定义限界模板
- DXF模板支持
- 限界测量报告生成
Scenarios
Applicable project scenarios
Typical project conditions where this offering may be relevant.
- Railway tunnel clearance measurement
- Metro tunnel clearance measurement
- Cross-section analysis
- Gauge template evaluation
- Vehicle profile clearance check
- Tunnel operation safety assessment
- 铁路隧道限界测量
- 地铁隧道限界测量
- 断面分析
- 限界模板评估
- 车辆轮廓限界核查
- 隧道运营安全评估
Technical Information
Technical parameters
- Output formats: CAD drawing and Excel report.
- Template support: Vehicle, profile, gauge, DXF.
- Measurement basis: Tunnel cross-section and point cloud data.
- Main output: Clearance gauge report.
技术参数
- 输出格式：CAD图与Excel报告。
- 模板支持：车辆、轮廓、限界、DXF。
- 测量基础：隧道断面与点云数据。
- 主要成果：限界测量报告。
